Century A.O. Smith – Squirrel Cage 56J 3 HP Three Phase Full Rated Pool Pump Motor, 9.6-9.2/4.6A 208-230/460V

Original price was: $361.00.Current price is: $97.99.

SKU: AW50A 627041 Categories: PARTS, Pool Pump Motors, Single Speed Pump Motors

100% environmentally friendly material
Secure Shopping with Safe Payments
The home of quality products.
Experience the difference quality makes.

Description
Reviews (0)

Squirrel Cage Centurion Square Flange Motors are premium replacement motors for pools and spas

Ball Bearings
Cast Iron NEMA C Bracket
50/60 Hertz
40 C Ambient
303 Stainless Steel Shaft
Class A or B Insulation
Reversible (Three Phase)

Squirrel Cage Centurion Square Flange Motors are premium replacement motors for pools and spas. These motors are protected from water damage and have high-quality ventilation openings. They are equipped with ball bearings and stainless steel threaded shafts for protection against premature deterioration and sport Class B insulation, which is designed to keep motors from overheating. Operating at 60HZ, Squirrel Cage Centurion Square Flange Pool and Spa Motors are available with a 56Y-Frame, 1/2″P-3HP, and 208-230/460V for ideal performance.

Phase Type:	Three Phase
Speed Settings:	Single Speed
Installation Type:	Residential
Horsepower:	3 HP
Voltage:	208 – 230V / 460V
Service Factor:	1.00 – 1.25
Shaft Type:	Threaded
Rating Type:	Full-Rated
Product Type:	Pool Motor
Motor Frame:	56 Frame
Energy Efficiency:	Standard
Manufacturer:	Century A.O. Smith
Warranty:	1-Year
